ZigZag Tree Traversal in Python (Time Complexity: O(N))

Given a binary tree, return the zigzag level order traversal of its nodes' values. (ie, from left to right, then right to left for the next level and alternate between).

Example:

Input: root = [3, 9, 20, null, null, 15, 7]
    3
   / \
  9  20
    /  \
   15   7

Output:
[
  [3],
  [20,9],
  [15,7]
]

Understanding the Problem

The core challenge of this problem is to traverse the binary tree in a zigzag manner. This means alternating the direction of traversal at each level of the tree. This type of traversal is significant in scenarios where hierarchical data needs to be processed in a non-linear fashion.

Common applications include visualizing hierarchical data structures, such as organizational charts or file systems, where a zigzag pattern can provide a more intuitive view.

Potential pitfalls include handling null nodes and ensuring the correct order of nodes at each level.

Approach

To solve this problem, we can use a breadth-first search (BFS) approach with a queue to traverse the tree level by level. We will use a flag to alternate the direction of traversal at each level.

Initial naive solution might involve using a simple BFS without considering the zigzag pattern, but this would not meet the problem requirements.

Optimized solutions involve using a deque to efficiently append nodes from both ends and a flag to track the direction of traversal.

Step-by-Step Breakdown

Initialize a queue with the root node and a flag to track the direction of traversal.
While the queue is not empty, process each level of the tree.
For each level, use a deque to store nodes in the correct order based on the current direction.
Append the values of the nodes in the deque to the result list.
Toggle the direction flag for the next level.

Code Implementation

import collections

# Definition for a binary tree node.
class TreeNode:
    def __init__(self, val=0, left=None, right=None):
        self.val = val
        self.left = left
        self.right = right

def zigzagLevelOrder(root):
    if not root:
        return []

    results = []
    node_queue = collections.deque([root])
    left_to_right = True

    while node_queue:
        level_size = len(node_queue)
        level_nodes = collections.deque()

        for _ in range(level_size):
            node = node_queue.popleft()
            if left_to_right:
                level_nodes.append(node.val)
            else:
                level_nodes.appendleft(node.val)

            if node.left:
                node_queue.append(node.left)
            if node.right:
                node_queue.append(node.right)

        results.append(list(level_nodes))
        left_to_right = not left_to_right

    return results

# Example usage:
# Construct the binary tree from the example
root = TreeNode(3)
root.left = TreeNode(9)
root.right = TreeNode(20)
root.right.left = TreeNode(15)
root.right.right = TreeNode(7)

print(zigzagLevelOrder(root))  # Output: [[3], [20, 9], [15, 7]]

Complexity Analysis

The time complexity of this approach is O(N), where N is the number of nodes in the tree. This is because each node is processed exactly once.

The space complexity is also O(N) due to the storage required for the queue and the result list.

Edge Cases

Potential edge cases include:

An empty tree (should return an empty list).
A tree with only one node (should return a list with one element).
Unbalanced trees where one subtree is significantly deeper than the other.

These cases are handled by the algorithm as it processes each node individually and does not assume a balanced tree.

Testing

To test the solution comprehensively, consider the following test cases:

Empty tree: root = None
Single node tree: root = TreeNode(1)
Balanced tree: root = [3, 9, 20, null, null, 15, 7]
Unbalanced tree: root = [1, 2, 3, 4, null, null, 5]

Use a testing framework like unittest or pytest to automate the testing process.

Thinking and Problem-Solving Tips

When approaching such problems, consider the following tips:

Break down the problem into smaller, manageable parts.
Use diagrams to visualize the tree structure and traversal process.
Start with a simple solution and iteratively optimize it.
Practice similar problems to strengthen your understanding of tree traversals and BFS/DFS algorithms.

Conclusion

Understanding and solving the zigzag tree traversal problem enhances your knowledge of tree data structures and traversal algorithms. It also improves your problem-solving skills by challenging you to think about different traversal patterns and their implementations.

Practice regularly and explore further to deepen your understanding and proficiency in solving such problems.
